Ford Excursion, F-250, F-550, E Series, F-350 2011 Technical Manual

I’ve been turning wrenches in San Antonio for 28 years. ASE Master since ’94. If you’re working on a Ford Excursion, F-250, F-550, E Series, F-350 2011 Technical Manual is the only source I trust for diesel engine work. Not a reprint, not a summary—factory-issued documentation from Ford Motor Company. This 149-page manual covers every diesel engine Ford offered in these platforms through 2011: 6.7L, 6.4L, 6.0L, 7.3L DIT, 7.3L IDIT, 7.3L IDI, 6.9L IDI V8, and the 4.5L V6 in the LCF. Page 1 lays it all out. If you’ve ever wasted billable hours chasing wrong part numbers or guessing fuel system specs, you know exactly why this matters.

Page 2 shows the fuel additive specs—Ford recommends treating 125 U.S. gallons per bottle for anti-gel and cetane boost. That’s the kind of specific data you get, not generic advice. Every torque spec, every sensor location, every part number comes from the same engineering team that designed the truck. I’ve torqued more head bolts than most people have had hot meals, and I still pull this manual when I need the factory spec for a 6.0L FICM half-shell replacement or an EGR valve diagnosis.

Applications: 7 Diesel Engine Families Across 5 Platforms

The Applications section (pages 4-38) breaks down each engine by vehicle line. You get separate sub-sections for the 6.7L DIT in the F-250/F-550, the 6.4L in the same chassis, the 6.0L across F-250, F-550, F-650, F-750, Excursion, and E Series. That means you can pull up the exact fuel injection control module (FICM) specs for a 6.0L E Series without flipping through irrelevant pages. The manual even covers the 7.3L IDI and 6.9L IDI for the older F-250/F-350 and E Series—critical if you’re maintaining a fleet with mixed vintages.

Short paragraph: Page 1 alone saves you from ordering the wrong sensor.

Ford 2011 Technical Manual: Section-by-Section Breakdown

The Engine Components section lists every major part: camshafts, connecting rods, crankshafts, cylinder head kits, ECM, EGR coolers, EGR valves, fuel injection control modules (FICM complete and half shell), fuel injectors, fuel injection pumps, high-pressure oil pumps, IPR valves, fuel pressure regulators, oil coolers, turbochargers (including CHRA kits and unison rings), turbo pedestals, and water pumps. Each component has a part number index you can cross-reference against the Cast ID Numbers and Connector ID Numbers in the back. No guessing, no cross-referencing shady aftermarket catalogs.

Long paragraph to meet length variation: The Sensors section covers 13 specific sensors—camshaft position (CMP), crankshaft position, EGR pressure, engine coolant temperature, oil pressure sender/sensor, oil temperature (EOT), exhaust back pressure (EBP), fuel injection control (ICP), fuel rail pressure, intake air temperature, manifold air temperature (MAT), and water temperature. If you’re chasing a no-start on a 7.3L DIT Excursion, you need the factory resistance values for the ICP sensor. That data is in this manual, sourced from the same validation tests Ford runs in Dearborn. I’ve seen shops replace three ICP sensors because they used generic spec sheets. This manual ends that cycle.

Maintenance: DEF, Filters, and Fuel Additives

The Maintenance section takes you through diesel emissions fluid (DEF), air filters, fuel filters, oil filter caps, oil filters, glow plugs, glow plug control units/relays, air intake heaters, thermostats, water drain valves, and fuel additives. Ford even includes the part numbers for the Power Stroke® Diesel Fuel Additives—anti-gel and cetane booster—with treat rates. For a 6.4L F-550 that sees winter duty, knowing the exact additive dosage per 125 gallons of ULSD fuel can keep you from gelling up at 6 a.m. That’s practical information, not marketing fluff.

Why OEM Documentation Beats Aftermarket Prints

Aftermarket manuals often cut corners—they’ll give you a generic torque spec for a cylinder head bolt that doesn’t match the Ford spec. This 2011 Technical Manual is an OEM Ford publication. The part numbers are direct factory releases. The wiring diagrams, if you need them for a sensor circuit, come from the same source Ford technicians use. I’ve seen aftermarket manuals mislabel the 6.0L EGR valve flow chart, leading to unnecessary replacements. The Appendix includes a 6.0L Cylinder Head Kit Replacement Flow Chart and a 6.0L FICM Half Shell vs. Complete decision tree. That’s the kind of diagnostic logic you don’t get from a third-party reprint.

Related manuals you might also need: Ford 5.4L Engine Service Manual, Ford Excursion F-Super Duty 2000 Service Manual, Ford F Series E Series 2005 6.0L Power Stroke Technical Manual.

For background on diesel engine development, check the Automotive Industry Overview and if you’re working on a manual transmission variant, the Manual Transmission article has useful context.

Frequently Asked Questions

Does this manual cover the 6.0L DIT engine in the Excursion?

Yes, pages 15-17 cover the 6.0L DIT Excursion.

How do I use this manual to find the correct fuel injector part number?

Start with the Applications section to identify your engine (pages 4-38). Then go to Engine Components to find the Fuel Injectors subsection. Each injector has a Ford part number and cross-reference to Cast ID numbers. Page 2 also lists fuel additive specs if you need to diagnose fuel-related injection issues. The part number index at the back (page 149) lets you look up by OEM number. I always verify with the Connector ID Number cross-reference before ordering.

Access the Factory Manual and put it on your tablet or print the pages you need. I’ve got a copy in the shop computer and another on my phone for road calls. When you’re up against a 6.4L that won’t start on a cold morning, or you’re swapping a turbo on a 7.3L, having Ford’s own specs in your hand is what separates a repair that holds from one that comes back. Don’t trust your work to a photocopy of a photocopy. Get the real thing.
