Fiat-allis 805 C Parts Catalog – 320-Page OEM Factory Manual

I’ve been turning wrenches since before most of you were born, and I’ve watched guys order the wrong bearing, the wrong seal, the wrong hydraulic line – then stand there scratching their heads while the machine sits dead. That’s why a Fiat-allis 805 C Parts Catalog from the factory isn’t optional; it’s the difference between a one-call parts order and a week of returns, reorders, and downtime. This is the same 320-page book Fiat Trattori handed to dealers. No reprints, no third-party photocopies – original print.

What This 320-Page Catalog Covers

You get the full breakdown of the 805 C. The table of contents lists every subgroup: engine, transmission, undercarriage, hydraulics, electrical – all split into parts plates. Each plate shows an exploded view with numbered callouts, and the corresponding list gives you the OEM part number, description, and quantity per machine. Page 5 lays out the ordering rules so you don’t send in a bad PO. Page 6 has the warnings on catalog interpretation – read that before you blame the diagram for your mistake. There’s also a model index on orange paper (page 11) and subgroup indexes starting at 17/1, plus a numeric index of part numbers at 19/1.

Ordering Parts the Right Way

If you’ve ever tried to order a part for an older machine using a generic cross-reference, you already know the pain. This catalog gives you the exact Fiat part number, no translation needed. The section “Norme per le ordinazioni” (ordering standards) tells you how to structure your order so the dealer doesn’t bounce it back. It’s in Italian, English, French, German, and Spanish – pick your language and go. I’ve used this catalog to order undercarriage parts for an 805 C that had been sitting in a field for ten years, and every part number matched what came in the box.

OEM vs Aftermarket: Why Factory Documentation Wins

I’ve seen aftermarket catalogs that list a part as “equivalent” and then give you three different dimensions – none of which fit. That doesn’t happen with a Fiat-allis factory print. The Parti di Ricambio section is broken into tables and lists exactly what was bolted on at the factory. You also get modification tables (page 1M) – updates Fiat made during the production run. You need those mods to know if your machine uses the old or updated part. No generic supplier includes that.

Real-World Use Case: Rebuilding the Undercarriage

Say you’re replacing track chains and sprockets on a 805 C. Open the catalog to the undercarriage subgroup. The exploded drawing shows you how every roller, carrier, and sprocket fits together. The table tells you the OEM part number for each component, plus the quantity – no guessing if you need four or six bolts per segment. I’ve done this job with the catalog open on the bench, and I didn’t waste a single trip to the dealer. If you’re working on larger Fiat-allis equipment, check out the Fiat-Allis HD41 Parts Catalog – 370-Page OEM Factory Manual for the big iron, or the Fiat-Allis 12G-B 1979 Parts Catalog – OEM Factory Manual 337 Pages for grader work. For loader models, the Fiat-allis 6G Parts Catalog – OEM Factory Manual 559 Pages covers that chassis.

How to Navigate the Catalog

Flip to the orange paper section – the model index. Find your 805 C variant. That gives you the subgroup numbers for your specific configuration. Then go to the subgroup index (page 17/1) to locate the exact parts plate. The numeric order index (page 19/1) lets you look up a part number and find which subgroup it belongs to. It’s a three-step process that takes ten seconds once you know it. The catalog also includes miscellaneous tables starting at page 1T: bearings, cable harnesses, terminal lugs, insulating tubes – all with factory part numbers. That appendix alone has saved me hours of hunting down electrical connectors.

3 Common Mistakes When Ordering Parts

First mistake: not checking the modification tables. If your 805 C was built after a certain serial number, the part may have changed. The Modifiche section (page 1M) lists those changes by serial number range. Second mistake: using a part number from a different subgroup. Just because a bolt looks the same doesn’t mean the threads or grade match. The catalog lists the exact fastener for each location. Third mistake: ignoring the ordering instructions on page 5. Some parts are sold only in kits, and the catalog tells you that upfront. A little reading now saves a lot of calls later.

For an overview of how these parts catalogs fit into the broader maintenance picture, the Automotive Industry Overview explains the role of standardized documentation. Also see Automotive Industry Overview for reference on factory spec adherence.

Is this catalog in English?

Yes. The text is in Italian, English, French, German, and Spanish. The English section starts at the front of the book.

What is the difference between a parts catalog and a service manual?

A parts catalog gives you exploded diagrams and OEM part numbers – it tells you what to order. A service manual gives you torque specs, clearance tolerances, and step-by-step repair procedures. If you are rebuilding an 805 C, you need both. The parts catalog gets the correct parts on the bench; the service manual tells you how to install them. I have seen guys try to rebuild an engine using only a parts catalog and end up with a stack of parts that fit but were assembled wrong. Don’t be that guy. Get the service manual too.

Can I use this catalog to order parts directly from Fiat?

These are the same part numbers Fiat dealers use. Give them the number from this catalog and they will pull the stock. Some older parts may be discontinued, but the number is still the key to finding NOS or aftermarket equivalents with known specs.

Does the catalog include exploded diagrams?

Yes. Each parts plate is a line drawing with numbered callouts. The corresponding list gives the part number and description.

I’ve been in this trade long enough to know that the machine doesn’t care about your feelings – it cares about the right part, torqued to the right spec, installed in the right sequence. Having the factory Fiat-allis 805 C Parts Catalog on your bench means you stop hoping and start knowing. Access the Factory Manual now and keep your 805 C working.
