Fiat-allis 350 Parts Catalog – Factory Parts Identification Without the Headaches

If you’ve ever ordered a part for a Fiat-allis 350 and got the wrong number because the counter guy used a third-party cross-reference, you already know the pain. This Parts Catalog is the original factory document – 257 pages, printed by FIAT in Turin, not a scanned-and-retyped copy from some reseller. I keep one in the shop for every job that involves a 350, whether it’s the undercarriage or the electrical system. When a customer wants a bearing or a cable boot, I don’t guess. I open the catalog and read the number straight off the plate.

The catalog is organized the way FIAT intended: subgroups, numerical index, and exploded plates. Page 9 (Use of the Catalog) tells you exactly how to read the part numbers and the code system. You get the Italian, French, German, English, Spanish – all in one book. The model list is on orange paper so you can find your specific 350 variant fast. That’s not a gimmick. It’s design that saves you from ordering the wrong final drive seal because you didn’t check the serial number range.

What’s Inside the Fiat-allis 350 Parts Catalog

The main body is the spare parts section: plates with exploded diagrams and the corresponding parts list directly above each plate. If you need the exact bolt or the hydraulic line bracket, the subgroup index (page 17/1) gets you to the right plate. The numerical index (page 19/1) lets you search by the factory part number if you already have one. After two decades turning wrenches, I tell apprentices: start with the subgroup list if you’re working from a visual, use the numerical list if you have a number from another unit. Both methods are covered in the catalog’s own instructions. No aftermarket catalog does this with the same clarity.

Bearings and Electrical Components: Tables You Can Trust

Section “Miscellanea” starts at page 1T with bearings – all the part numbers for every rolling element used on the 350. Then you get electrical cables (page 3T), terminals and boots (page 4T), and insulation tubes (page 5T). These tables aren’t vague descriptions. They list the exact cable length, the terminal stud size, and the insulation material. I’ve had jobs where a frayed wire needed the original boot, and the parts guy swore it was discontinued. I flipped to page 4T, found the cap part number, called FIAT’s old-stock supplier, and got it. The catalog paid for itself that week.

Why OEM Documentation Over Aftermarket Copies

I’ve seen too many aftermarket parts catalogs that swap part numbers or leave out the modification tables. This catalog includes a dedicated “Modifications” section (page 1M) where FIAT listed engineering changes – things like a revised brake band or an updated gasket kit. If you use a generic catalog, you won’t know about the change, and you’ll order the wrong piece. The Automotive Industry Overview makes the same point: factory documentation is the only reliable source for serial-number-specific parts. I won’t put a part on a customer’s machine unless I’ve verified it in the OEM catalog. Period.

How This Catalog Fits Your Shop Workflow

When a 350 comes in with a blown steering clutch, you don’t have time to cross-reference three websites. Open this catalog to the transmission subgroup, pull the plate, and read the part number. Then call the supplier with the exact FIAT reference. The 257 pages cover everything from the engine to the electrical harness. If you need a full undercarriage set for a different model, check the related manuals. I keep the Fiat-Allis HD41 Parts Catalog – 370-Page OEM Factory Manual for the big tractors, and the Fiat-Allis 12G-B 1979 Parts Catalog – OEM Factory Manual 337 Pages for graders. For the 6G loaders, the Fiat-allis 6G Parts Catalog – OEM Factory Manual 559 Pages is the same level of detail. All original prints, no reprints.

The automotive industry depends on accurate parts identification. Without it, you waste time, money, and customer trust. The external resources like Automotive Industry Overview confirm that OEM data is the foundation of proper repairs. This catalog is that foundation for the Fiat-allis 350.

FAQ

Does the catalog include part numbers for the engine and transmission?

Yes. The subgroup index covers engine, transmission, final drive, and all other major systems. Use the subgroup index (page 17/1) or the numerical index (page 19/1) to find any part.

How do I identify the correct bearing for a 350 final drive?

Go to the Miscellaneous Tables, page 1T, which lists all bearings used on the 350. The table includes the FIAT part number, the bearing industry number, and the quantity per machine. Cross that with the exploded plate in the spare parts section to confirm the location. The catalog also gives the exact part numbers for the seals and snap rings – everything you need to rebuild the final drive without returning to the parts counter halfway through the job. I’ve done it. The table is complete once you understand the use instructions on page 9.

This catalog is the one I reach for every time a 350 comes through the bay. No guesswork, no aftermarket cross-reference that might be wrong. Access the Factory Manual and put the original FIAT parts data on your workbench.
