Champion 700 SERIES GRADER, 730 1993 Training Manual

You’ve got a 730 grader in the bay that’s leaking from the moldboard drift, and the customer wants it fixed yesterday. Thing is, you need the cushion valve pressure and the counterbalance valve sequence, and the aftermarket CD you bought last year has the wrong psi values. I’ve seen guys turn a 30-minute adjustment into a four-hour headache because they guessed the lock valve setting. Stop burning billable hours. This Champion 700 SERIES GRADER, 730 1993 Training Manual is the one Champion gave their own techs. 59 pages of factory procedure, not some reprint from a scanner.

Front Axle Oscillation and Toe-in: Get It Right

Section 8 covers the oscillation, leaning wheel, and toe-in adjustments. The manual tells you the pivot points and the sequence for the 730 front axle. If you ignore the toe-in spec, the front tires scrub and the steering hydraulic system fights itself. Page 16 gives you the main relief valve setting—do not exceed that number. I’ve had a tech crack a steering gear because he cranked the relief up thinking more pressure equals better steering. It doesn’t. The training manual explains the hydraulic circuit so you understand why the valve opens at that pressure. Manual Transmission is not the same as a hydraulic circuit, but the same logic applies: follow the spec or fail.

Main Hydraulic System: Cushion Valve, Lock Valve, Counterbalance

Champion designed the main hydraulic system with a cushion valve that absorbs blade shock loads. Page 18 is dedicated to that valve. The lock valve on page 20 holds the blade in position when you’re grading slopes—if it leaks, the blade drops. The counterbalance valve on page 22 controls lowering speed. You need to know the difference between a lock valve and a counterbalance, or you’ll install the wrong part. The manual covers each valve with cross-section illustrations and flow paths. That’s what a training manual does: it teaches you how the system thinks.

Circle Timing and Set-Up: The Hidden Adjustment

Most guys hate setting circle timing because it’s fiddly. Page 34 walks you through the circle timing and set-up procedure for the 730. You rotate the circle, check the backlash, and adjust the drive pinion engagement. If you get the timing wrong, the circle will bind when you turn it under load. The manual shows you the indexing marks and the order of operations. Champion 720, 710A, 780, 780A 1991 Training Manual – Factory Specs covers similar setups for other models if you’ve got a mixed fleet.

Model 8400 Transmission: Clutch Packs and Oil Circuits

Page 42 dives into the Model 8400 transmission. The double clutch pack on page 46 is where most transmission failures happen. The manual explains the oil circuit for first forward gear on page 44—you need to understand which clutch engages and why the oil pressure has to be within 10 psi of spec. The engine clutch on page 40 is a mechanical link that wears over time; the manual gives the adjustment procedure and the free-play measurement. Don’t use a generic hydraulic schematic from the internet; the 8400 has a specific shuttle valve sequence that’s easy to misread.

Service Brakes: Hydraulic Circuit and Oil Disc Brakes

Brake failures on a grader are not a joke. Page 52 covers the service brake hydraulic circuit, including the master cylinder pushrod adjustment and the bleeding sequence. The oil disc brakes on page 54 use a wet clutch system—if you use the wrong fluid, the discs swell. The training manual lists the approved brake fluid type and the torque for the caliper bolts. I’ve seen a shop put DOT 3 into a wet brake system and destroy the seals in two hours. This manual prevents that kind of mistake.

3 Systems That Require Factory Specs

The electric float valve (page 24), solenoid operated valves (page 26 and 28), and the All Wheel Drive System (page 56) all have calibration steps that change based on serial number range. Your 730 falls between 21911 and 24735. The manual was printed in 1993 by Champion Road Machinery Limited, part number L-5005. That means the solenoid valve current draw values and the AWD pressure switch settings are original factory data. Champion 700 Series Grader Series III Training Manual is the same manual you’re looking at, only for the Series III variant. This one covers both Series III and earlier models.

Source Validity: OEM Training Manual vs. Aftermarket

I’ve tested aftermarket manuals that claim to be OEM—half of them have redacted pages or blurred torque specs. This is a scanned original Champion training manual, 59 pages. The watermark says “©1993 Champion Road Machinery Limited”. No reprint house copied and guessed. If you need a wiring diagram for the solenoid valves, it’s on the original Champion drawings. Champion Road Machinery 700 Series Service Training is another sister document that goes deeper into diagnostics, but this training manual gives you the theory first.

Every time I open an aftermarket manual and see “check the manufacturer’s specs” written in the torque table, I know it’s garbage. This manual gives you the number. Manual Transmission analogies don’t cut it when you’re under a 30,000-pound grader. Get the real book.

Frequently Asked Questions

Does this manual cover the 730 model specifically?

Yes. The manual covers 700 Series graders including the 730 with serial numbers 21911 to 24735.

What torque specs are included?

The manual includes OEM torque specifications for hydraulic valves, transmission components, and brake systems. You will find specific values in each section. For example, the main relief valve section on page 16 gives pressure settings, and the oil disc brake caliper bolts have listed torque values on page 54.

Is this a service manual or a training manual?

This is a factory training manual used by Champion technicians. It explains system operation, adjustment procedures, and troubleshooting. It is not a step-by-step repair manual but provides the foundational knowledge needed to service these graders correctly. You will learn how each hydraulic circuit interacts, which is critical before you start disassembling components. Use it alongside the Champion service manual for specific repair procedures.

Can I use this for a 780A?

Yes. The manual covers models 710 through 750A and also includes a dedicated front axle section for 780/780A on page 10. The steering and main hydraulic systems are shared across most of the 700 Series, so the training applies.

If you’re tired of guessing and want the same training Champion paid for, Access the Factory Manual. It’s the difference between a comeback and a finished job.
