Case CX160B 2007 Parts Catalog – Undercarriage Hydraulics

If you’re wrenching on a Case CX160B and need to track down the exact O-ring for the center joint or a hydraulic hose assembly for the travel motor, you don’t have time to guess. I’ve seen guys order three different seals before getting the right one because they used an aftermarket parts list. Waste of a morning. This is a 2007 original factory Parts Catalog from Case – 30 pages covering the undercarriage hydraulics section. No third-party reprint, no scanned copy with blurred part numbers. The part numbers in here are the ones Case stamped on the line.

Why a Factory Parts Catalog Saves You Time

Every time I get a CX160B in the shop with a hydraulic leak, the first thing I do is pull the factory parts catalog. Not the service manual – the parts catalog. Because the service manual tells you how to remove the travel motor, but it doesn’t list the exact port connector thread size or the O-ring dash number. This catalog does. Section 07-001-00 has the hydraulic circuit layout with callouts – you see part number 151654A1 for a 3/4″ NPT O-ring connector. That’s the piece that threads into the swing joint. If you order a generic 3/4″ adapter from the hardware store, you’ll be chasing leaks for a week. Trust the OEM number.

Undercarriage Hydraulics: What the 30 Pages Cover

The catalog breaks down into five sub-sections: hydraulic circuit (two variations), swing joint, and travel motor (three variations). Each page shows an exploded diagram with labeled components, a part number, description, and quantity. For example, on page 2 you’ll see the traction motors, center joint, hoses, connectors, o-rings, buffer rubbers, and mounting clips. The table lists every item – from the 1800mm hose assembly (KLA10210) to the 1/2″ NPT connector (151650A1). No guessing what thread pitch or hose length you need.

Using the Catalog with a Service Manual

I always tell my junior techs: parts catalog and service manual are a pair. The service manual gives you the torque sequence for the travel motor mounting bolts. The parts catalog gives you the part number for the o-ring under that mounting flange. For a full service manual to match your parts catalog, grab the CASE CX160B CX180B 2007 Service Manual”>CASE CX160B CX180B 2007 Service Manual. And if you’re chasing electrical gremlins at the same time, the Case CX Series Electrics Layout Diagram Training Manual”>Case CX Series Electrics Layout Diagram Training Manual will keep you from splicing the wrong wire.

Swing Joint and Travel Motor: Exploded Views

Section 07-010-00 covers the swing joint – that rotating seal between upper and lower structures. The diagram shows the center joint with its internal O-rings (part 154467A1 and 154487A1) and the four mounting clips (150071A1). The travel motor sections (07-011 and 07-012) have two different variations – one with a 1800mm hose, one with a 2350mm. If you’re replacing a travel motor on a CX160B, you need the correct hose length for your serial number range. The catalog doesn’t list serial numbers, but it does show which version of the motor is installed. Measure your hose before ordering, or cross-reference with the Case CX160B CX210B CX240B CX290B AC Troubleshooting Manual”>Case CX160B CX210B CX240B CX290B AC Troubleshooting Manual for diagnostic procedures.

Verifying Part Numbers Before You Order

Take the O-ring 154523A1 – listed in the catalog for the 1/2″ NPT connector. If you walk into your local hydraulic shop and say “I need a 1/2″ NPT O-ring,” they might hand you a standard SAE dash 6. That’s wrong. That O-ring has a specific ID and cross-section. The factory number ensures you get the exact seal. The same goes for hoses – the catalog lists assembly part numbers, not just hose length. KAJ3096 is a 2350mm hose assembly with the correct end fittings. Ordering by the factory number means it will bolt on without adapters. For a broader look at the heavy equipment world, check the Automotive Industry Overview or this Automotive Industry Overview”>Automotive Industry Overview for context on OEM documentation standards.

Does this parts catalog include torque specs or repair instructions?

No. This is strictly a parts catalog – exploded diagrams and part numbers. You need the service manual for torque values and removal procedures.

How many pages does it have?

30 pages, exact OEM, all English with German/French/Spanish translations in the tables.

Will this catalog work for a Case CX210B or CX240B?

Only for the CX160B undercarriage hydraulics. Undercarriage components differ between models. You need the specific catalog for your machine – the service manual covers multiple models but the parts catalog is model-specific. Using the wrong one will give you incorrect part numbers for hoses, motors, and seals.

Are the part numbers still valid today?

They were current as of 2007. Case may have superseded some numbers. Always check with your dealer before ordering, but the catalog gives you a starting point that’s far more reliable than a generic cross-reference.

The bottom line: If you need to order parts for a CX160B undercarriage, stop guessing. Access the Factory Manual and have the correct part numbers on your bench before you pick up the phone. It’s 30 pages that pay for themselves the first time you avoid ordering the wrong travel motor hose.
