BMW 325i, 318i, 318is, 325is 1993 Troubleshooting Manual – Factory Electrical Schematics

Alright, listen up. You’re fighting an electrical ghost on an E36 325i. Customer says the ABS light is on and the radio cuts out when the brakes are applied. Before you start swapping modules or chasing ground loops with a test light, you need the factory schematic book. This is that book. The BMW 325i, 318i, 318is, 325is 1993 Troubleshooting Manual – a 334-page OEM troubleshooting manual that covers vehicles produced from 09/92 to 08/93. Part number 01 00 1 468 774. No redrawn diagrams, no guessing at pin colors. BMW NA printed this in Woodcliff Lake, NJ, and it’s the exact same binder the dealer techs used to diagnose these cars when they were new.

What you get is the full electrical architecture for the 1993 model year E36. Turn to page 1 and you see the cover; flip to page 2 and you’ll find the complete index listing every component from ABS Hydraulic Unit to Wiper/Washer Module. This is not a service manual – it’s a troubleshooting manual. It tells you where the voltage should be at each pin, what each connector looks like, and which splice location to check when the circuit goes dead.

Why Factory Schematics Beat Aftermarket

I’ve seen aftermarket wiring diagrams that have the wrong pin numbers for the DME M3.3.1. That mistake will cost you a burned ECU or a misdiagnosed crank sensor. This manual is the original BMW document – the same one used by the dealer network. It includes power distribution charts (0670.0), fuse details (0670.3), ground distribution (0670.4), and the data link connector (0670.5). Every splice location is mapped in section 8000.0. Every connector view is in section 8500.0. You don’t need to guess where the break is – you can trace the wire from one end to the other using the actual factory color codes and terminal numbers.

Engine Control: DME M1.7 and DME M3.3.1

Two separate engine management systems are covered. For the 4-cylinder M42 in the 318i and 318is, section 1210.9 details the DME M1.7. For the 6-cylinder M50 in the 325i and 325is, section 1210.13 covers the DME M3.3.1. Each section includes complete wiring schematics, component locations, and signal descriptions. If you’re troubleshooting a no-start, you can find the crankshaft sensor input, the fuel injector triggers, and the ignition coil drivers. The charging system (1230.0) and starting circuit (1240.0) are also here. This manual gives you the voltage values and pin assignments so you can verify with a multimeter instead of throwing a new DME at the car.

Transmission, ABS, and Airbag – Factory Procedures Only

Do not rely on aftermarket info for the Electronic Transmission Control (EGS A4S 310R) in section 2460.2, the Supplemental Restraint System (SRS) in section 3234.0, or the Slip Control (ABS) in section 3450.0. These systems have specific diagnostic sequences and safety procedures. On the airbag circuit, you need to know exactly how to discharge the capacitor and which terminal on the clock spring supplies the driver’s bag. The manual shows the gas generators (G5 for driver, G6 for passenger) and the crash control module (6350.0). Guessing can deploy a bag in your face – or cause a false deploy that costs thousands.

Which Technician Needs This Manual?

If you’re a DIY owner working on a 1993 318is or a professional tech in a shop that sees older BMWs, this manual belongs on your bench. The component location views (7100.0) show you where every sensor, relay, and control module lives. The connector views (8500.0) give you the exact cavity numbering. When the customer’s cruise control (Tempomat) stops working, instead of tracing every wire blindly, you go to section 6571.0 and find the switch supply, the actuator signal, and the control module pinout. No wasted hours. No second trips to the parts store for a relay that wasn’t the problem.

Do not guess on airbag circuits. Use the factory procedure.

FAQ – Common Questions About This Manual

What models does this manual cover?

Covers 1993 BMW 318i, 318is, 325i, and 325is (E36).

Does this manual include wiring diagrams for the engine control system?

Yes. Sections 1210.9 and 1210.13 provide complete schematics and component location for the DME M1.7 (4-cylinder M42) and DME M3.3.1 (6-cylinder M50). These cover fuel injectors, ignition coils, crankshaft and camshaft sensors, idle control, and the charging system (section 1230.0) and starting system (1240.0). The manual also includes the data link connector (0670.5) for diagnostic access. With this book, you can trace a no-start back to a specific pin at the DME without relying on aftermarket pinouts that are sometimes wrong.

Is this a repair manual or a troubleshooting manual?

This is an electrical troubleshooting manual, not a service manual. It covers wiring, component locations, connector views, and fuse details. For engine removal or transmission overhaul, you’d need the separate service manual.

Can I use this manual to fix a non-start issue on a 1993 325is?

Absolutely. This manual gives you the complete wiring for the engine control, start, and charging systems. Start with the power distribution chart (0670.0) to verify voltage at the DME, then trace signals using the DME schematics.
