Atlas Copco CC234C, 334C, CC2300C, 3300C Operators Manual – Factory Specs for Vibratory Rollers

If you’re running a CC234C or 334C on a job site and you’ve got a hydraulic leak or a warning light flashing, the last thing you need is a generic repair guide that guesses at pressures. I’ve seen more than a few rollers come into my shop with stripped fittings because some tech used a torque spec from a third-party website. This Atlas Copco CC234C, 334C, CC2300C, 3300C Operators Manual is the factory document—160 pages of the exact procedures Atlas Copco wrote for these machines. No aftermarket reprints, no assumptions.

The manual covers both Tier 3 (Cummins QSB 3.3) and Tier 4i (Deutz TCD 3.6 L04) engine options, serial number ranges from 10000314x0A010759 onward. You get the original instruction book, translated from Swedish, printed in 2014. Every spec in here matches what the assembly line used.

Safety Systems: Slopes and Edge Operation

Most roller accidents happen on slopes or near edges. The manual dedicates pages 7-8 to slope operation and driving near edges. It tells you the maximum grade you can work on and how to position the drum when turning. Page 7 covers the slope limits for the CC2300C and 3300C models specifically. If you skip this section, you’re gambling with a rollover. I’ve pulled two machines out of ditches because the operator thought they could handle a steeper grade than the factory allows. Don’t be that guy.

The optional equipment section includes air conditioning, edge cutter/compactor, and Xenon working lights. That’s on page 9. Not many aftermarket manuals bother with those details.

160 Pages of Factory Operating Instructions

You get 160 pages total. The Table of Contents starts on page 3: Introduction (page 1), Safety – General instructions (page 5), Safety – when operating (page 7), Special instructions (page 11), Technical specifications (page 15). Every chapter is here. The technical specs include vibrations at operator station, noise levels, electrical system data, dimensions, weights, working capacity, and hydraulic system pressures. Page 15 lists electrical system voltage (24V) and alternator output. Page 18 gives you working capacity in tons and drum width. That data matters when you’re matching the roller to the job.

What Torque Values Are Listed?

Torque specs appear throughout the maintenance sections—wheel nuts, hydraulic fittings, engine mounts. The manual references tightening torques for bolts and nuts in the hydraulic system table on page 20. You won’t find those numbers in a generic operator’s handbook. I’ve had guys snap bolts because they used a standard automotive torque for a roller’s hydraulic pump bracket. Use the factory values or you’re buying parts.

Understand the Safety Procedures Before You Operate

The manual opens with a full safety section: general instructions, CE marking, and battery handling. Jump starting procedure for a 24V system is on page 13. That’s critical if you’re working remote. It also covers high pressure cleaning hazards and fire fighting steps. Page 12 tells you how to handle the ROPS cab and battery disposal. Read that before you put a wrench on anything.

Lubricants and Fluids: Factory Recommendations

Special instructions on page 11 list standard lubricants and oils, plus warnings for high ambient temperatures (above +40°C / 104°F) and freeze risks. The manual specifies the exact oils for the hydraulic system, engine, and vibration system. If you’re working in extreme heat or cold, those temperature ranges keep your components alive. I’ve seen rollers with cooked hydraulic fluid because someone ran standard 10W-30 in a Texas summer. The factory says otherwise.

Related Manuals for Atlas Copco Equipment

If you need more on other Atlas Copco machines, check out the Atlas Copco XAHS 146 Dd 2006 Operators Manual – Factory Specs”>XAHS 146 Dd 2006 Operators Manual for compressor specs. The Atlas Copco Boomer L1 D L2 D ML2 D Mark VII 2008 Operators Manual”>Boomer L1 D L2 D ML2 D Mark VII 2008 Operators Manual covers drill rigs. And the Atlas Copco XRHS 486 Md, XRHS 396 Md, XRVS 466 Md, XRVS 346 Md 2005 Operators Ma”>XRHS 486 Md series operators manual is for portable compressors. For general drivetrain background, read about Manual Transmission”>Manual Transmission basics or dive into Manual Transmission”>Manual Transmission repair if you’re working on older equipment.

Frequently Asked Questions

Does this manual cover the CC2300C and 3300C models?

Yes. The manual covers CC234C, 334C, CC2300C, and 3300C. All engine variants (Cummins and Deutz) are included. Serial numbers for each model are listed on page 1.

What about jump starting procedures for a 24V system?

Page 13 gives the factory procedure for jump starting a 24V system. It warns about battery polarity, cable gauge, and arc prevention. The manual also specifies that you must not connect a 12V battery to these rollers. I’ve seen jumper cables melt because someone ignored that. Follow the steps exactly.

Stop hunting through forums for half-correct specs. Access the Factory Manual and get the real data from Atlas Copco. Every page is the same document that ships with the machine.
