Atlas Copco CC1100, CC1200 Operators Manual

I’ve seen guys blow up a roller because they guessed the hydraulic torque and used a crescent wrench on a ROPS bolt. That’s why you need the Atlas Copco CC1100, CC1200 Operators Manual on your bench, not some aftermarket reprint. This is the original 120-page factory document that came with the machine. It tells you exactly what lubricant to run when the ambient temp hits 104°F, what the tightening torque is for the ROPS bolts, and which serial numbers fit. If you’re working on a CC1100 or CC1200 with a Kubota D1703 engine, this is the only document you should trust.

Torque Specs and Fluid Capacities You Can’t Guess

Page 16 lists the tightening torque for the whole machine, plus a separate table for ROPS bolts and the hydraulic system. I’ve seen what happens when a roller loses its ROPS on a slope because the bolts were torqued by feel. The manual gives you the numbers in Nm and lbf·ft – use them. It also covers standard lubricants and what to switch to when the mercury goes above +40°C. No guesswork.

Safety – When Operating Near Edges and on Slopes

The section on Safety when operating (pages 7-8) is not filler. It spells out the distances to keep from edges and the maximum slope angle you can work. If you’ve ever had a roller slide sideways on a wet grade, you know why those pages exist. The manual also includes fire fighting instructions, battery handling, and jump starting procedures. That’s stuff you hope you never need, but when you do, having the factory steps saves your skin.

Does This Manual Cover the D1703 Engine?

Yes, the engine plates are listed in the Identification section (page 20). The manual covers both the CC1100 and CC1200, which run the Kubota D1703 diesel. You get dimensions (top and side views on pages 12-13), weights, volumes, and working capacity specs. If you’re swapping an engine or rebuilding the hydraulic pump, that information saves hours of hunting. Don’t rely on a sketch from a forum.

3 Reasons to Choose OEM Documentation Over Aftermarket Copies

1. Factory torque values. Aftermarket reprints often omit the tightening torque tables or copy them wrong. This manual has the exact specs Atlas Copco published.
2. Serial number alignment. The manual lists specific serial number ranges (e.g., 10000367xFA0xxxxx – 10000371xFA017074). You can verify it fits your machine.
3. Safety warnings that match the machine. The ROPS, battery handling, and freeze risk instructions come straight from the manufacturer. No generic boilerplate.

Audience Fit – Who Needs This Manual

If you’re a shop owner or a field mechanic who touches compactors, keep this PDF on your tablet. Home garage enthusiasts who bought a used CC1100 or CC1200 – you need the page on high pressure cleaning (page 9) to avoid driving water into electrical connections. Beginners will find the intended use and warning symbols section (page 1) essential. Don’t skip the CE marking page (page 3) if you’re working in regulated environments. The Manual Transmission section doesn’t exist here – these rollers use hydrostatic drives – but the manual does cover the hydraulic system torque values that apply to the drive motors.

Source Validity – This Is Not a Reprint

AutoRepairManuals stocks the largest collection of OEM shop manuals in North America. This Atlas Copco CC1100, CC1200 Operators Manual is a direct scan of the factory document (part number 4812162201.pdf). No reprints, no third-party summaries. The OCR excerpt shows the table of contents and first pages – I can see the 17-digit serial number breakdown and the machine plate location. That’s the stuff aftermarket houses fake. If you need parts, pair this with the Atlas Copco CC1100 CC1200 Operation and Maintenance Manual for the full service schedule. Other related manuals include the Atlas Copco XAHS 146 Dd 2006 Operators Manual – Factory Specs for air compressor users, and the Atlas Copco Boomer L1 D L2 D ML2 D Mark VII 2008 Operators Manual for drill rig techs. If you’re into automotive, check out the Manual Transmission section on our site for car stuff – but for compactors, this Atlas Copco manual is it.

Do I need the operation and maintenance manual in addition to this operators manual?

If you plan to do major overhauls, yes. The operators manual covers daily checks and safe operation. The separate maintenance book has intervals and procedures.

Does this manual give me the tightening torque for every bolt on the roller?

It gives the torque for ROPS bolts and hydraulic system connections. For other general bolts, page 16 has a standard tightening torque table based on bolt grade and thread size. That covers 90% of what you’ll need. If you’re doing engine internal work, you need the engine service manual.

Stop chasing specs on forums and wasting billable hours. Access the Factory Manual from AutoRepairManuals and get the torque right the first time.
